Custom Home Appliance Speaker Box

Changzhou Haoxiang Electronics Co., Ltd. Home / Products / Speaker / IOT Speaker Box
  • Product parameters:


    Dimension (mm): 230x27.5xH28.2
    AC Resistance: 8±15%Ω
    S.P.L.(dB): 82±3dB
    Res. Freq.(Hz): 160±20%
    Freq. Range: F0~ 20K Hz
    Rated Power: 5W
    Operate temp: -20~+60℃
  • Product parameters:


    Dimension (mm): 202x18xH35
    AC Resistance: 8±15%Ω
    S.P.L.(dB): 78±3dB
    Res. Freq.(Hz): 350±20%
    Freq. Range: F0~ 20K Hz
    Rated Power: 5W
    Operate temp: -20~+60℃
  • Product parameters:


    Dimension (mm): 108x22xH35
    AC Resistance: 8±15%Ω
    S.P.L.(dB): 78±3dB
    Res. Freq.(Hz): 350±20%
    Freq. Range: F0~ 20K Hz
    Rated Power: 5W
    Operate temp: -20~ +60℃
  • Product parameters:


    Dimension (mm): 101*47*H22
    AC Resistance: 4±15%Ω
    S.P.L.(dB): 84±3dB
    Res. Freq.(Hz): 280±20%
    Freq. Range: F0~ 20K Hz
    Rated Power: 3W
    Operate temp: -20~ +60℃
  • Product parameters:


    Dimension (mm): 99.5x45xH20
    AC Resistance: 2±15%
    S.P.L.(dB): 91±3
    Res. Freq.(Hz): 100±20%
    Freq. Range: F0~ 20K Hz
    Rated Power: 4W
    Operate temp: -20~ +55℃
  • Product parameters:


    Dimension (mm): 99x44.5xH20
    AC Resistance: 4±15%
    S.P.L.(dB): 97±3
    Res. Freq.(Hz): 100±20%
    Freq. Range: F0~ 20K Hz
    Rated Power: 3W
    Operate temp: -20~ +55℃
  • Product parameters:


    Dimension (mm): 85x18xH13
    AC Resistance: 8±15%Ω
    S.P.L.(dB): 78±3dB
    Res. Freq.(Hz): 350±20%
    Freq. Range: F0~ 20K Hz
    Rated Power: 5W
    Operate temp: -20~ +60℃
  • Product parameters:


    Dimension (mm): 78x36xH23.5
    AC Resistance: 4.0±20%
    S.P.L.(dB): 93±3
    Res. Freq.(Hz): 200±20%
    Freq. Range: F0~ 20K Hz
    Rated Power: 3W
    Operate temp: -20~ +60℃
  • Product parameters:


    Dimension (mm): 70x30xH16.5
    AC Resistance: 4±20%
    S.P.L.(dB): 80±3
    Res. Freq.(Hz): 150±20%
    Freq. Range: F0~ 20K Hz
    Rated Power: 10W
    Operate temp: -20~+60℃
  • Product parameters:


    Dimension (mm): 70x30.5xH16.6
    AC Resistance: 4±15%Ω
    S.P.L.(dB): 95±3
    Res. Freq.(Hz): 250±20%
    Freq. Range: F0~ 20K Hz
    Rated Power: 3W
    Operate temp: -20~ +60℃
  • Product parameters:


    Dimension (mm): 70x28xH16.8
    AC Resistance: 4±15%Ω
    S.P.L.(dB): 90±3dB
    Res. Freq.(Hz): 300±20%
    Freq. Range: F0~ 20K Hz
    Rated Power: 2.5W
    Operate temp: -20~ +60℃
  • Product parameters:


    Dimension (mm): 50x35xH23
    AC Resistance: 4±15%Ω
    S.P.L.(dB): 90±3dB
    Res. Freq.(Hz): 300±20%
    Freq. Range: F0~ 20K Hz
    Rated Power: 2.5W
    Operate temp: -20~ +60℃

Home Appliance IOT Speaker Box Manufacturers

TDA company independent research and development of a number of speakers, with development patents.
It is used for voice broadcasting in the Internet of Things, with independent music playing function, and the sound quality is clear and loud.
It is suitable for home appliance display panel and multimedia playback with Internet of Things function.
about TDA

Our story

Founded in 2002, TDA is a self-registered brand in China. The company is currently implementing IATF16949 and ISO13485 quality management systems. Home Appliance Speaker Box Manufacturers and Wholesale IOT Speaker Box Suppliers and Factory in China. By December 2022, TDA will have 4 production factories in Changzhou, Nantong, Chongqing, and Qingdao. The company's current main customers include B/S/H, Panasonic, GEA, Audi, Haier, etc. The company mainly produces various electroacoustic devices and injection molding parts, including various buzzers, car speakers, 5G speakers, coil speakers, microphones, etc. It has several independent research and development patent projects, among which piezoelectric speakers are used in many special fields due to their ultra-thin features. The products are mainly used in various home appliances, automobiles, security, medical and other industries. The company has self-supporting import and export rights, and its products are mainly exported to Europe and North America. The products meet the EU RoHS and REACH standards.
  • 4

    Production Factory

  • 21+

    Inudstry Experience

  • 300+

    Staff Member

Qualification Certificates

As Customized Home Appliance Speaker Box Suppliers, The company is currently implementing IATF16949 and ISO13485 quality management systems. The products meet the EU RoHS and REACH standards.

  • IATF16949IATF16949
  • IATF16949IATF16949
  • ISO45001ISO45001
  • ISO14001ISO14001
  • ISO13485ISO13485
  • Trademark registrationTrademark registration
  • PatentsPatents
  • PatentsPatents
  • ISO13485ISO13485
  • ISO14001ISO14001

News

Industry Knowledge

What is IOT SPEAKER BOX?

An IOT (Internet of Things) speaker box refers to a speaker box or enclosure that is equipped with IoT capabilities. It combines traditional speaker functionality with connectivity to the internet, allowing it to interact with other devices, services, and platforms within an IoT ecosystem.
Here are some key features and capabilities commonly associated with IoT speaker boxes:
Wireless Connectivity: IoT speaker boxes typically support wireless connectivity options such as Wi-Fi, Bluetooth, or both. This enables seamless communication with other devices, such as smartphones, tablets, or smart home systems.
Multi-Room Audio: IoT speaker boxes can be part of a multi-room audio system, where multiple speakers in different rooms are interconnected. This allows synchronized playback of audio content throughout the house, controlled from a central device or through voice commands.
Smart Home Integration: With their IoT capabilities, these speaker boxes can be integrated into smart home ecosystems. They can serve as a central control hub for other smart devices, allowing users to control lights, thermostats, security systems, and other connected devices through voice commands or mobile apps.
Notifications and Alerts: IoT speaker boxes can receive and relay notifications or alerts from other connected devices or services. For example, they can announce incoming calls, calendar events, weather updates, or provide reminders.
Interoperability: IoT speaker boxes often support interoperability with other IoT devices and protocols, enabling them to work seamlessly with a wide range of smart home devices, sensors, and platforms.
Firmware Updates and Cloud Connectivity: IoT speaker boxes can receive firmware updates over the internet, ensuring they remain up to date with the latest features and security patches. They may also have cloud connectivity, allowing users to access and control the speaker remotely from a smartphone or web portal.
Overall, an IoT speaker box enhances the functionality and versatility of a traditional speaker by integrating it into a connected ecosystem, providing additional features, and enabling seamless integration with other devices and services within the Internet of Things paradigm.


What IOT SPEAKER BOX Are Used For?

IoT speaker boxes have a variety of applications and use cases. Here are some common examples:
Smart Home Control: IoT speaker boxes serve as a central control hub for smart home devices. Users can use voice commands to control lights, thermostats, security systems, and other connected devices. They can also set up routines or automation scenarios where specific actions are triggered based on voice commands or predefined conditions.
Entertainment and Media Streaming: IoT speaker boxes provide access to streaming services such as music, podcasts, and online radio stations. Users can use voice commands to play their favorite songs, create playlists, or discover new content.
Multi-Room Audio: With IoT speaker boxes, users can create a multi-room audio system where speakers in different rooms are interconnected. They can play synchronized audio content throughout the house or control individual speakers in specific rooms.
Notifications and Reminders: IoT speaker boxes can provide notifications and reminders for various events, such as incoming calls, calendar events, or reminders set by the user. Users can hear these announcements without needing to check their phones or other devices.
Voice-controlled Smart Assistants: IoT speaker boxes can act as a voice-controlled smart assistant for users, providing information, recommendations, and assistance in various tasks. Users can ask questions, get real-time information, and access a wide range of services and functions using voice commands.
Intercom and Communication: Some IoT speaker boxes support intercom functionality, allowing users to communicate with other speakers or connected devices within the same network. This feature can be useful for intra-house communication or for monitoring and communicating with people in different areas of a building.
Personalized Experiences: IoT speaker boxes can learn user preferences and behaviors over time, providing personalized recommendations, customized playlists, and tailored content based on individual preferences.
These are just a few examples of how IoT speaker boxes are used. Their versatility, integration capabilities, and voice control features make them valuable devices for enhancing smart home experiences, entertainment, and convenience in various settings.
